VIMEC GROUP ITALIA

 Vimec Group Italia is one of the top Italian valve companies for design, manufacturing and supply of high-quality industrial valves under the trademark of Vimec Valves.

We designed and manufactured in accordance with major international standards and our Research & Development team continuously strive to develop, improve and streamline our designs for optimal performance and reliability.

Our experienced and qualified staff are able to design, manufacture, assemble and test the valves at 100% to satisfy a wide range of customer requirements. Our technical department prepares 2D, 3D drawings and analyzes the request from our client’s project specifications.

In order to meet client’s requirements, our technical department offers the most suitable and appropriate product solutions as per the international standards such as ASME, API, Norsok to mention a few.

 Vimec Valves are manufactured in Italy at a modern facility in Cividate Al Piano, Bergamo, Italy, strategically placed its new production facility at the global hub of oil and gas valve manufacturing, where dense networks of valve components suppliers are located.

The main products include Double Block and Bleed Ball Valves, Floating & Trunnion Ball Valves, Manifolds, Monoflanges, Needle Valves, Gate Valves, Globe Valves, Swing Check Valves, Piston Check Valves, Dual Plate Check Valves, Butterfly Valves, Motor Operated Valves and Emergency Shutdown Valves.

The highest quality and variety of materials used such as carbon steel, low carbon steel, stainless steel, alloy steel and other exotic special alloy steel can satisfy all the requirements of the oil & gas, chemical, petrochemical and power plants.

Our facilities and capabilities include:

• State-of-the art ERP manufacturing business system
• Proven, experienced components supply chain
• 2D and 3D CAD Design
• Mill Reports with full material traceability
• NDE – including UT, Radiograph, PMI, DPI, MPI etc
• Precision valve assembly
• Pressure testing – Hydrostatic, Pneumatic and HP Gas
• Fugitive Emissions testing
• Painting as per customer specification
• Packing & worldwide shipping.

 Vimec Group Italia has implemented a Quality Management System and state-of-the-art ERP aimed at achieving customer satisfaction by meeting customer requirements while observing the laws of applicable regulations for Quality, Environment, Health and Safety.
Quality, technology and reliability in service are guaranteed by qualified and experienced personnel operating in the engineering department, workshop, assembling and testing area with the support of advanced machinery.
We are highly experienced in project management and encourage stage wise inspection and customer visits.
The company policy of growth and improvement, as well as the control of the entire production chain, has prompted Vimec Group Italia to initiate certification for Integrated Quality and Safety Management Systems.

• ISO 9001:2015  • PED DIRECTIVE 2014/68/EU

 • API 6D • FIRE SAFE
• FUGITIVE EMISSION ISO 15848-1

• ATEX • ACHILLES • 77/300 TAT


 Vimec Integral Double Block & Bleed Valves are equipped with a drain needle valve mounted between the two balls, this permits to drain the valve and reset the pressure to zero.

Integral DBB Valve are used in the instrumentation systems and are available in combination of Flange to Flange, Flange to Thread, BW and Hub Ends. Injection and Sampling with Ball and Needle Configurations.

Design Features

• Compact single piece forging
• Size range : ½” to 4”
• Rating : ANSI 150# to 2500#, API 3000 to API 10,000
• Ends : Screwed, Flanged RF, RTJ in combination
• Internal bore diameter: 10, 14 and 20 mm
• Non-rotating tip needle valve for smooth operation and minimum wear of the sealing elements
• Bolted bonnet with anti-blow-out (anti-ejection system to guarantee safety)
• Soft seated & metal seated
• Antistatic and anti blow out stemdesign
• Lip seal design
• Low emission design
• Cryogenic application upon request
• Operation: Lever, Gear, Pneumatic or Electrical Actuator

Design Standards

• Designs to ANSI B16.34, API 6D, API 6A
• Flanges to ANSI B16.5
• Material according to NACE MR-0175
• Testing to API 598, API 6D
• Fire safe to API 607, API 6FA, ISO 10497

Materials
Carbon Steel, Stainless Steel, Low Temp, Alloy & Duplex Steel. Special Testing such as HP Gas Test, IGC, HIC, Fugitive Emission ISO 15848 Part 1 & 2 and also Special painting is offered upon request.

 Vimec Valves Modular Double Block & Bleed Ball Valves are equipped with a drain needle, ball or DBB valve mounted between the two balls, this permits to drain the valve and reset the pressure to zero.

The main characteristics of this design is double isolation with two independent balls in one valve body, guaranteeing positive shut off with maximum safety with DIB-1, DIB-2 features.

Design Features

• Size Range : ½” to 3” for Instrumentation / 1” to 36” for Pipeline Valves
• Rating : 150# to 2500#, API 3000 to API 10,000
• Ends : Flanged RF, RTJ, BW, Hub End Connections
• Full Bore / Reduced Bore
• Soft seated & metal seated
• Antistatic and anti blow out stemdesign
• Lip seal design
• Spring loaded seats
• DIB-1, DIB-2
• Low emission design
• Sealant injection upon request
• Cryogenic application upon request
• Operation: Lever, Gear, Pneumatic or Electrical Actuator

Design Standards

• Designs to ANSI B16.34, API 6D, API 6A, API 608
• Face to face to ANSI B16.10
• Flanges to ANSI B16.5, B16.47
• Top flange to ISO 5211
• Material according to NACE MR-0175
• Testing to API 598, API 6D
• Fire safe API 607, API 6FA, ISO 10497

Materials
Carbon Steel, Stainless Steel, Low Temp, Alloy & Duplex Steel. Special testing such as HP Gas Test, IGC, HIC, Fugitive Emission ISO 15848Part 1 & 2 and also special painting is offered upon request.

 Vimec Valves Compact Design valves utilize a face to face dimension of a single ball valve in accordance with API 6D and yet this design is double isolation with two independent balls in one valve body, guaranteeing positive shut off with maximum safety with DIB-1, DIB-2 features.

Vimec Valves has developed compact design with continuous research to improve and meet customer’s requirements and expectations as a completion of its Double Block & Bleed Valves range. The design has been developed with integral flange connections into the valve body in order to achieve a short face-to-face dimension as a single block ball valve with light weight, which means the valve can easily be installed into an existing pipeline without the need for any pipeline re-working.

Design Features

• Size Range : 2” to 36”
• Rating : 150# to 2500#
• Ends : Flanged RF, RTJ, BW
• Full Bore / Reduced Bore
• Soft seated & metal seated
• Antistatic and anti blow out stemdesign
• Lip seal design
• Spring loaded seats
• DIB-1, DIB-2
• Low emission design
• Sealant injection upon request
• Cryogenic application upon request
• Operation : Lever, Gear, Pneumatic or Electrical Actuator

Design Standards

• Designs to ANSI B16.34, API 6D
• Face to face to ANSI B16.10
• Flanges to ANSI B16.5, B16.47
• Top flange to ISO 5211
• Material according to NACE MR-0175
• Testing to API 598, API 6D
• Fire safe API 607, API 6FA, ISO 10497

Materials
Carbon Steel, Stainless Steel, Low Temp, Alloy & Duplex Steel. Special Testing such as HP Gas Test, IGC, HIC, Fugitive Emission ISO 15848. Part 1 & 2 and also Special painting is offered upon request.

 Vimec Valves produces needle and gauge valves designed to work with any gas or fluid. They are built to withstand a pressure of 6,000 PSI and come with a PTFE gasket pack. They can also be customized according to the sector's most common requirements and reach a pressure of 10,000 PSI. The gasket pack is available in Graphoil or other materials upon request.
Needle Valves are made from bar-stock.

Vimec Valves can also offer Needle Valves with twin ferrule compression ends. This combination is an alternative to threaded connections to eliminate the use of thread sealant, consequently reduction of leak is guaranteed.

Design Features

• Size Range : ¼” to 1-1/2”
• Rating : 6000, 10000, 15000 psi
• Ends : Threaded NPT, BSPT, BSPP, SW, BW
• Bore : 4, 5 mm
• Bolted Bonnet Design
• Non-Rotating Tip Needle Valve for smooth operation and minimum wear of the sealing elements
• Bolted Bonnet with anti-blow-out (anti-ejection system to guarantee safety).
• Operation : T-Lever, Isolate Anti-Tamper, Padlock for all Anti-Tamper bonnet

Design Standards

• Designs to ANSI B16.34
• Material according to NACE MR-0175
• Testing to API 598

Materials
Carbon Steel, Stainless Steel, Low Temp, Alloy & Duplex Steel.

 Vimec Valves Monoflanges are used in upstream offshore/onshore gas and oil production and initial processing installation.

Our Monoflanges are produced with the aim of uniting primary, secondary, and vent valves in a single body, replacing the connection to the plant by flanged threading. They are available in 4mm, 10mm bore diameter typically used in gas gauge pressure instrument applications to minimize the size and the weight of the pipeline valve assemblies used for primary and / or secondary isolation, vent and calibration.

This is the purpose of eliminating any possible contamination of the fluid with thread sealants. The monoflanges can therefore be fixed onto any desired pipe, resulting in faster installation and better operating efficiency.

It is also used in downstream oil and gas refining and petrochemical production.

 Vimec Valves offers a wide range manual valves designed for various applications suitable for instruments and line cut-off on steam and high pressure fluids.

These valves are suitable for standard and critical applications where high resistance to pressure temperature and corrosion are of primary importance and when tight shut-off time performance and long lasting equipment are required.

All our manifolds are made from bar-stock and available with ¼”and ½” size connections with pressure ratings of 6000, 10000 and 15000 psi.

Standard connections are Threaded NPT, BSPT or BSPP and they are also available with SW and BW ends.
